Scotch Yoke Pneumatic Actuator
>
Scotch Yoke Pneumatic Actuator Double Action Single Action pneumatic cylinder
|
Scotch Yoke Pneumatic Actuator Double Action Single Action pneumatic cylinder
| Place of Origin | China |
| Brand Name | OEM |
| Certification | CE,ATEX,ISO9001 |
| Model Number | B08-B4 |
Product Details
Type:
Double Action Single Action
Material:
Aluminum Alloy
Structure:
Scotch Yoke
Application:
Automatic Control Valve
Power:
Pneumatic
Temperature:
Normal Temperature,Low Temperature,High Temperature
Media:
Hydraulic Oil Or Water
Color:
Blue,gray,according To Customer's Requirements,customized
Size:
32 To 400
Highlight:
Scotch Yoke Pneumatic Actuator double action
,Aluminum alloy pneumatic actuator
,Scotch Yoke Actuator with warranty
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
10-2000
Packaging Details
Foam+Carton Box+Wooden Case
Delivery Time
3-7 days
Payment Terms
T/T
Supply Ability
1000pcs per day
Product Description
Big Output Torque Scotch Yoke Pneumatic Actuator
Product Specifications
Our high-performance pneumatic actuator features a scotch yoke mechanism for big output torque applications.
| Attribute | Value |
|---|---|
| Type | Double Action / Single Action |
| Material | Aluminum Alloy |
| Structure | Scotch yoke |
| Application | Automatic control valve |
| Power | Pneumatic |
| Temperature Range | Normal Temperature, Low Temperature, High Temperature |
| Media | Hydraulic oil or water |
| Color Options | Blue, gray, or customized to customer requirements |
Key Features
- Rotary Angle: 0~90 degree
- Working Pressure: 2~8bar
- Surface Treatment: Hard anodizing for enhanced durability
- Multiple temperature ranges available:
- Normal Temperature: -20°C to +80°C
- High Temperature: -15°C to +150°C
- Low Temperature: -40°C to +80°C
- Standard connections: NAMUR, ISO5211 and DIN3337
- Available in multiple colors: grey, black, sky blue, dark blue, red, orange
- External stroke adjustment bolts for precise ±5° adjustment
- Available in both double acting and spring return configurations
Technical Advantages
Our AT series pneumatic actuators incorporate the latest technology and innovative design features:
- Full conformance to ISO5211, DIN3337, VDINDE-3854, and NAMUR standards
- Honed internal surface with hard anodized coating for long service life
- High-quality bearings for low friction and quiet operation
- Pre-compressed load spring for safe mounting and disassembly
- Multiple O-ring materials available for different temperature requirements
- Easy mounting of solenoid valves without additional connecting planks
Applications
Our pneumatic actuators are suitable for various demanding environments including flammable, corrosive, dusty, and high-vibration conditions. Ideal for use in:
- Electric power plants
- Petrochemical facilities
- Oil and gas operations
- Water treatment plants
- Chemical processing
- Mining operations
- Food and pharmaceutical production
Dimensions
| B06/C06 | 50x90 | 80x90 | 4-M8x15 | 4-M8x15 | 80 | 30 | 30 | 290 |
| B08/C08 | 50x90 | 80x90 | 4-M12x18 | 4-M12x18 | 80 | 30 | 30 | 372 |
| B1/C1 | 80x125 | 80x125 | 4-M12x18 | 4-M12x18 | 80/130 | 30 | 30 | 426 |
| B2/C2 | 80x125 | 100x160 | 4-M12x18 | 4-M12x18 | 80/130 | 30 | 30 | 480 |
| B3/C3 | 80x180 | 120x210 | 4-M12x18 | 4-M12x18 | 80/130 | 30 | 30 | 583 |
| B4/C4 | 80x180 | 120x230 | 4-M12x18 | 4-M12x18 | 130 | 30 | 30 | 680 |
| B5/C5 | 80x220 | 140x300 | 4-M12x18 | 4-M12x18 | 130 | 30 | 30 | 810 |
| B6/C6 | 80x220 | 180x400 | 4-M12x18 | 4-M12x18 | 130 | 30 | 30 | 1060 |
